Long Duration Aluminum Honeycomb Panels , Honeycomb Material
Customized Size
Aluminum Honeycomb Panels
Light Weight High Strength Long Duration Aluminum Honeycomb Panel
With Customized Size
Product Property
As a product specially for aerospace industry use which is highly
required on quality, Aluminium Honeycomb Core (AHP) possesses
unique advantages against any other decoration material.
| 1. Light weight, energy conservation, decreasing object loading,
easy to be installed, maintained and recycled. |
| As the same stiffness to aluminium plate and steel plate, the
weight of AHP is just 1/5 of aluminium plate and 1/10 of steel
plate. The weight of an AHP with total thickness of 10mm including
0.5mm face sheet, 0.5mm back sheet is only 3kg per square meter
which is 2 kg lighter than 4mm thick Aluminium Composite Panel
(ACP) including o.5mm face sheet and 0.5mm back sheet but twice
stiffness more than ACP and the same as 4mm aluminium sheet. The
performance and cost ratio is significantly higher than the one ACP
and aluminium sheet. It can effectively save materials. |
2. High strength, suitable stiffness, not easy to deform and high
loading bearing capacity |
As the aluminium honeycomb stressing in the vertical direction and
there are many fixed honey combs in a panel, so the panl will be
very stable and keep its form unchanged even impacted by external
strength. |
| 3,Good sound, heat, thermal insulation, moisture-proof and fireproof
performance, non-toxic and environmental protection |
| As the honey combs are sealed airtight to prevent air from flowing
between them so that the sound transmission and thermal
conductivity coefficient of the panel have been greatly decreased
because the sound wave and heat have been effectively impeded
accordingly. Therefore, with good functions of sound, thermal and
heat insulation, it can save insulation materials. |
| 4. High peeling strength and weather fastness, enduring finish
paint luster, resistance to weather and chemical corrosion and
being luxury and wearing well. |
With aviation adhesive under high temperature and suitable
pressure, the aluminium sheets and honeycomb core are combined
together to be AHP which possesses significantly high stability
after cooling and thus should not peel at ambient temperature. The
coating material of AHP is Polyvinylidene Fluoride (PVDF) which can
meet the quality standards of globally accepted building industry
AAMA605.2.92 and thus the AHP can resist every current pollutants,
corrosion of acid rain, strong ultraviolent rays radiation,
weathering and washing. Its strong corrosion resistance can secure
coating not fade and crack for more than 20 years. |
Application:
Interior Room Decoration
Partition Serious, Clean Workshop, Bath Partition, Office
Partition, High Partition Wall, Furniture and et al
AHP, which possesses sound and thermal insulation, fire resistance,
heat preservation, corrosion resistance, environment protection,
resistance to shock and high planeness characteristics, is the
first choice of material used for clean workshop, bath partition,
office partition, high partition wall and furniture.
Transportation
AHP, originally used in aviation industry, was widely popularized
rapidly in transportation industry as its high strength, light
weight, firer resistance, heat preservation, sound insulation and
shockproof characteristics.
Elevator Project
Marble Aluminium Honeycomb Panel, as its high strength, light
weight, firer resistance, heat preservation, sound insulation, high
load-bearing and shockproof, can greatly decrease the carrier’s
load and is suitable for making elevator.
Furniture Ceiling
Metal partition for toilet
Aluminium Honeycomb Panel is combined with 3003H24 high quality
aluminium plate coated with polyester or PVDF roller painting and
core, a hexagon aluminium honeycomb structure, which are like
I-shape beam tied with each other spreading pressure from face
plate to make face plate bearing average force so as to secure high
planeness of the face plate. 6003 high strength industrial
aluminium profile is used for edge sealing with the surface
oxidized or spray painted to be artistic and high strength.
Sandwich panel composite process make our AHP better performance.
As its inherent properties of high planeness, waterproof, weather
and pollutant resistance, light weight, incombustible, easy to
handle on site et al, it has completely solved problems caused by
previous materials used in bath partition and now is a best choice
for top grade bath partition material.
