FRP Aluminium Honeycomb Panel with the Gel Coat Coated and Edge Folded For the Compartment Wall Use

Product Description

The FRP (Fiber Reinforced Plastics) aluminum honeycomb panel is comprised of two fiberglass reinforced platic surface plates, high-strength glass fiber plain woven cloth and aluminum honeycomb core material by a hot pressing process. Because of the high strength of the fiberglass woven cloth, the composite plate has a high impact force and flexural strength.

Main features:

1, Anti-weather performance: FRP sheets is a thermosetting polymer material with good heat resistance performance and application temperature range between -70 ℃ ~ 80 ℃.

2, impact resistance: as the product structure containing crisscrossed of glass fiber reinforced material, the shock resistance of the product has been greatly improved. It is not easy to break under the impact of gravel and hail.

3. Corrosion resistance: as the ability to resist all kinds of acid, alkali and other chemical corrosion, it is especially suitable for coastal and corrosive places' use.

4. The high quality color gel coat coated on the surface of the fiberglass honeycomb panel is of excellent performance and the food grade of international certification.It has good chemical stability to the atmosphere, water and general concentration of acid, alkali and salt. It is also because of this special coating, the surface of the car has a high gloss, excellent protection of light, no discoloration, corrosion resistance and very suitable for bright color car advertisement.

5. The light weight of the fiberglass honeycomb panel is much lighter than the wood composite plate and steel box, which can effectively reduce the carriage body weight, increase the load and improve the quality coefficiency of the van.

6. The fiberglass honeycomb plate adopts the aluminum honeycomb core material as the sandwich structure thus the compartment panel is very rigid, which can avoid the shake during transportation.

7. The repair of the glassfiber reinforced plastic honeycomb panel is very easy, after the repair without obvious repair marks which is greatly better than steel or aluminum compartment panels

Application scope:

Glass fiber reinforced plastic honeycomb panel is a kind of important engineering metope material which can solve the problems of traditional metope materials such as deformation not easy to clean, easy to sag, installation difficulties, poor durability, easy to wear and week impact resistance. It has been gradually replaced the stainless steel plate, aluminum plate, color steel plate, tile or paint, widely used in transportation and construction industries.

Mechanical Properties

Application:
